Laser VCSEL high-power medical beauty therapy specialized 808nm infrared cob light source
Product Feature:
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
★800-816nm laser infrared cob light source
Product Use:
★Stage Light,Decorative Light
★Laser hair removal device, laser welding, welding fill light, etc
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
★800-816nm laser infrared cob light source
Product Use:
★Stage Light,Decorative Light
★Laser hair removal device, laser welding, welding fill light, etc
Laser VCSEL high-power medical beauty therapy specialized 808nm infrared cob light source
规格 Datasheet
| 型号 Part No. |
功率 power (W) |
波长/色温 wavelength(nm)/ Color temperature（K） |
光功率 optical power（W） |
电压 VF (V) |
电流 IF (mA) |
角度 Angle (deg) |
| JH-25IR18DG4748-T18C-JLS808 | / | 800-816 | 75 | 8.5-11 | 1500-3500 | 18-24 |
Note: Can be customized on request
