Product centerHOME > Product description > All In One

product picture

80W ultra bright RGBW four-color color light COB

Product Feature:
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★SMD substrates,good heat sink
★Good bright spots and High bright

Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc

80W ultra bright RGBW four-color color light COB​



规格Datasheet

型号
Part No.		 功率
Power
(W)		 波长
Wavelength
​(nm)
/色温
CCT
(K)		 光通量
Luminous
(lm)		 电压
Voltage
(V)		 电流
Current
(mA)		 角度
Angle
(deg)
JH-80RGBW14S38-NC-N457.5 80 620-625nm 990-1010 23-25 700 140
520-525nm 1740-1760 31-33 700
455-460nm 480-500 29-31 700
6000-7000k 1990-2100 28-30 700

注：可按需定制
Note: Customizable
