15W high-power RGBWWW ultra bright color light five in one integrated light source
Product Feature:
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
★Five in one ultra-high brightness color light
Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
★Five in one ultra-high brightness color light
Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc
15W high-power RGBWWW ultra bright color light five in one integrated light source
规格 Datasheet
| 型号 Part No. |
功率 Power (W) |
波长/色温 WLD(nm) /CCT(K) |
光通量 Lumen (lm) |
电压 VF (V) |
电流 IF (mA) |
角度 Angle (deg) |
| JH-15RGBWWW14G40-R9C | 15 | 620-630nm | 120-150 | 6-7 | 350 | 140 |
| 515-525nm | 180-210 | 9-11 | 350 | |||
| 460-470nm | 60-80 | 9-11 | 350 | |||
| 6000-8000k | 270-300 | 9-11 | 350 | |||
| 2800-3400k | 270-300 | 9-11 | 350 | |||
| JH-15RGBWWW14G45-R9C | 15 | 620-630nm | 180-220 | 6-7 | 350 | 140 |
| 515-525nm | 300-340 | 9-11 | 350 | |||
| 460-470nm | 80-100 | 9-11 | 350 | |||
| 6000-8000k | 300-340 | 9-11 | 350 | |||
| 2800-3400k | 300-340 | 9-11 | 350 |
Note: Customization is available upon request!
